Product Introduction
Technical parameters
Plexiglas glove box model
Glove box number descriptionGBT Product code (Transparent Glove Box)
10 Material thickness (optional 10---30mm)
A Dimensions and models (Type A, Type B, Type C, Type D)
Swipe right to see more
| Product model | Box size (mm) | Material | Cabinet thickness (mm) | Transition room dimensions | Remark |
|---|---|---|---|---|---|
| GBT-10A | 700×450×500 |
Plexiglass or acrylic |
10 | none | Isolated and dust-proof, no vacuuming |
| GBT-15A | 15 | 240×240×240 | Micro vacuum can be equipped with water and oxygen removal purification system | ||
| GBT-30A | 30 | Vacuum to -0.1MPA, replace oxygen and water | |||
| GBT-10B | 1000×500×500 |
Plexiglass or acrylic |
10 | none | Isolated and dust-proof, no vacuuming |
| GBT-15B | 15 | 240×240×240 | Micro vacuum can be equipped with water and oxygen removal purification system | ||
| GBT-30B | 30 | Vacuum to -0.1MPA, replace oxygen and water | |||
| GBT-10C | 1200×600×600 |
Plexiglass or acrylic |
10 | none | Isolated and dust-proof, no vacuuming |
| GBT-15C | 15 | 240×240×240 | Micro vacuum can be equipped with water and oxygen removal purification system | ||
| GBT-30C | 35 | Vacuum to -0.1MPA, replace oxygen and water | |||
| GBT-10D | 1200×800×700 |
Plexiglass or acrylic |
10 | none | Isolated and dust-proof, no vacuuming |
| GBT-15D | 15 | 240×240×240 | Micro vacuum can be equipped with water and oxygen removal purification system | ||
| GBT-30D | 35 | Vacuum to -0.1MPA, replace oxygen and water |
Special customization
Working Principle
During scientific experiments, some substances are easily oxidized and deliquesced in the atmosphere, which makes the chemical reaction of the test substance and the pre-processing of the sample very difficult, affecting the test process and test results. The plexiglass vacuum glove box (also known as the vacuum inert gas operating box) effectively solves these problems. This device allows the test samples to be safely put in and taken out, and can be operated, reacted and tested freely in an oxygen-free and water-free state, ensuring the normal conduct of scientific experiments.
Product Features
01 It has a simple structure, is easy to use, can transmit UV light, and is lightweight.;
02 Under normal conditions, its shape is stable, highly transparent, and resistant to chemical corrosion and climate change.;
03 The box is equipped with multi-hole electrical sockets to facilitate scientific experiments.;
04 It has good sealing performance and can shield and absorb α-rays and low-energy β-rays emitted by radioactive materials to protect human tissue from damage by ionizing radiation. Therefore, it can cooperate with scientific research units in conducting experimental work on low-energy radioactive substances, aseptic operations on microbial inoculation, and qualitative and quantitative analysis of chemicals, and other related closed isolation operations, all of which can be performed in the operation box.
