Product Introduction
It is used for mixing and scrubbing in laboratories of mining and scientific research departments such as geology, metallurgy, building materials, and chemicals, and is especially suitable for separating and selecting small amounts of mineral samples.
Technical parameters
| project | unit | GFX 5-35 | GFX 50-100 | |
| volume | ml | 20/60/100/140 | 200/400 | |
| capacity | gram | 5/15/25/35 | 50/100 | |
| Impeller speed | change /point | 0-2600 | 0-2600 | |
| Impeller diameter | mm | 18/26/26/30 | 36/ 48 | |
| Spindle motor | model |
| YS-5612 | YS-5612 |
|
| power |
| 220V/ 380/ 90W | 220V/ 380/ 120W |
|
| Speed | change /point | 2800 | 2800 |
| Feeding particle size | mm | 0.05-0.2 | 0.05-0.2 | |
Product Features
1. The flotation speed is fast and the selection index is good.
2. Adjustment is convenient and accurate, and operation is reliable.
3. Analysis of low-grade ore and rare mineral samples.
4. The enrichment ratio requires a small amount of mineral samples to be carefully selected.
5. Inflatable hanging tank flotation machine (optional), the hollow shaft is designed with large inflation volume, central inflation, and stepless speed regulation by frequency converter.
